Saturday, August 30, 2014

Filesnakes, Wartsnakes, or Elephant Trunksnakes

Arafura Filesnake (Acrochordus arafurae)
In the swamps, marshes, streams, and estuaries of northern Australia and southeastern Asia live ancient snakes as thick as your arm, with tongues as thin as a thread, skin as rough as a file, and a disposition as gentle as a lamb. These snakes comprise the family Acrochordidae (from the Greek akrochordon, wart), and are known as filesnakes1, wartsnakes, or elephant trunksnakes. In Indonesian they are known as karung, which means 'sack'; in Thai, as ngū nguang-cĥāng, 'elephant-trunk snake'. There are three species, all in the genus Acrochordus: Javan (A. janavicus), Arafura (A. arafurae), and Little (A. granulatus). The largest, female Javans, grow up to 8 feet and over 20 pounds. Acrochordids are an old and highly distinct group of snakes, distantly related to colubroids, with which they share a common ancestor between 50 and 70, but possibly as long as 90 million years ago.

Close-up of A. arafurae scales
Filesnakes have strongly-keeled scales with the texture of sandpaper or a coarse file, after which they are named. They have very loose, baggy skin. I held one once and it felt like a human arm inside the sleeve of a very sturdy, very baggy rain poncho made out of chain mail. This loose skin is likely an adaptation that allows filesnakes to withstand the great force of the initial dash for freedom of their fish prey. Their sharp scales are used to help gain purchase on slimy fish skin during constriction. They have sensory, bristle-bearing tubercles on the skin between their scales, as well as sensory organs on the scales themselves, both of which presumably help them sense the underwater movements of nearby prey, analogous to the lateral line systems of fishes and some amphibians. Acrochordids sometimes ambush their prey, but more often they forage by searching slowly along the edges of mangroves, billabongs, and other water bodies at night, looking for sleeping fishes and crustaceans (although they don't tear them apart like some southeast Asian snakes). During the day, filesnakes hide in the shadows of overhanging trees, moving with them to remain concealed from predatory birds. They are nearly incapable of moving on land, and shed in the water using a knotting behavior similar to that of Pelamis platurus, the most completely aquatic sea snake.

Acrochordus arafurae regurgitates
an eel-tailed catfish (Tandanus tandanus)
whose spine has pierced its neck
Filesnakes occupy a unique phylogenetic position, not closely related to anything but somewhere in-between the colubroids ("advanced snakes") and the "henophidians" (boas, pythons, and other stem-group snakes). A few recent papers reanimate an old hypothesis that they might be closely related to dragonsnakes, but historically acrochordids have been considered the sister group to all colubroids, a group of >2,850 species (>80% of all living snakes) that includes dragonsnakes, asymmetrical slug-eaters, vipers, homalopsids, elapids, lamprophiids, and strict colubrids. Colubroidea and the three Acrochordus species together form the Caenophidia ("recent snakes"). Acrochordids share unspecialized head scales and undifferentiated ventral scales with boas and pythons, but they are united with colubroids in that they totally lack vestigial limbs and have spines on their hemipenes, a well-developed vomeronasal system, and several particular characteristics of skull morphology, including a coronoid bone. Other features of the skull and skeleton are unique to acrochordids, including the aforementioned skin sense organs, a passive joint between the frontal and parietal skull bones, the presence of certain holes in the vertebrae, the shape of the head of the ribs, and an ear region that most closely resembles the ears that other snakes have as embryos, but which forms in a different way. Acrochordids also have an unusual lung morphology, with a double row of holes leading from the trachea into individual small lunglets, and a more tangled intestinal tract than other snakes.

Acrochordus granulatus with algae growing on its back
Filesnakes have incredibly low metabolic rates, even for a snake, and cannot sustain rigorous physical activity for very long. In captivity, they "epitomize sluggishness in snakes", although radio telemetry has shown that in the wild they move around wetlands slowly but steadily, covering up to 450 feet per night. They can remain submerged for over an hour (record 2 h 20 min), and surface to take about 5 breaths, about one per minute. The first three to four of these breaths oxygenate the blood, and the last one fills the lung. In addition, Little Filesnakes have about twice as much blood as other snakes, and this voluminous blood is about twice as thick with red blood cells as even that of other diving snakes. Their hemoglobin has a very high affinity for oxygen, which results in their being able to store far more oxygen in their blood than a similarly-sized sea snake, and release it slowly over a long period of time. Many turtles also use this strategy. Also like turtles, filesnakes can both obtain oxygen from and release acidic carbon dioxide into the water through their skin, which helps prolong their dives. In fact, filesnakes are so well-adapted to sitting still that they are practically incapable of exercise, and get tired out quickly.

Overall, filesnakes have a slow life history. Males mature around six years old, females around nine, and 8-10 years may elapse between births. Studies from northern Australia found that only a small proportion of females are reproductive in any given year, and that only the very largest females reproduce relatively frequently. Large Javan Filesnakes give birth to as many as 52 young at once, although the average is closer to 30. Arafura Filesnakes average about 16 (as few as 9 and as many as 25 have been reported), and Little Filesnakes about 6 (as few as 1 and as many as 12). Female filesnakes are courted by up to eight males at a time in shallow water. Their population dynamics are driven by rainfall in northern Australia. One captive filesnake gave birth to a single young after seven years of isolation, suggesting that filesnakes are either capable of parthenogenesis or of very prolonged sperm storage.

The Little Filesnake (Acrochordus granulatus) has
a banded pattern like a sea krait (Laticauda colubrina)
At first glance the three extant Acrochordus species seem quite similar, but in fact they exhibit striking differences in both anatomy and ecology. The Little Filesnake (Acrochordus granulatus) was described in 1799 and used to be classified in a separate, monotypic genus (Chersydrus). As its name suggests, it is the smallest acrochordid (~ 3 feet in total length) and the most widely distributed. It is found along the coast from northwestern India throughout southeast Asia and Indonesia, reaching east to the Solomon Islands. Its diverse habitats include freshwater lakes, rivers, mangroves, mudflats, reefs, and the open ocean, up to 6 miles offshore and over 60 feet deep. It is the most marine of the filesnakes, the most brightly patterned, and has a shorter, more laterally-compressed tail, more granular scales, more dorsally-oriented nostrils, and a salt excretion gland beneath its tongue.

Acrochordus javanicus
The Javan Filesnake (Acrochordus javanicus) was the first to be described, in 1787, and is the largest and heaviest filesnake, sometimes reaching 8 feet and over 20 pounds. It is found in fresh and brackish water on the Malay Peninsula and on the islands of Sumatra, Java, and Borneo (and was introduced to Florida in the 1980s, although it does not appear to have established there). It is harvested for meat and for its skin, out of which is made fine leather; up to 2 million are exported from Indonesia annually. Unlike other filesnakes, the posterior-most teeth in its lower jaw have sharp edges. The Arafura Filesnake (Acrochordus arafurae) was thought to be the same species as the Javan until 1979. It grows as long but at the same size is only about half as heavy-bodied. It is found only in freshwater habitats in northern Australia and southern New Guinea. Surprisingly, A. arafurae is more closely related to A. granulatus than either is to A. javanicus, a relationship that is supported by genetics as well as morphology.

The long, thin tongue of Acrochordus javanicus
From Greene (1997)
Fossil Acrochordus have been found in Pakistan and Nepal, as well as within the extant range. These extinct filesnakes date from 5-20 million years ago during the Miocene, only a few million years after the Indian plate crashed into Asia to form the Himalayas. They grew larger than modern filesnakes, reaching at least 9 feet, and are the most well-represented snakes in the southern Asian fossil record, possibly because their habitat lends itself well to fossilization. The extinct species Acrochordus dehmi is represented by over 1000 fossils from over 100 different locations, and probably went extinct about 6 million years ago. Because it is so well-known, we can say with confidence that it is more closely related to A. javanicus than to the other two living species of AcrochordusMolecular clock methods suggest that the three modern species of Acrochordus and A. dehmi diverged from one another 16-20 million years ago, a timescale that usually justifies separation into family-level or higher categories. Despite their superficial similarities, the ecological and morphological differences among the three living Acrochordus species have been considered equivalent to differences among genera in other groups of snakes. Because no fossil acrochordids have been found in Australia, it is assumed that they evolved in Asia and spread to Australia in the last 5 million years. It is also likely that the ancestors of the Little Filesnake entered the ocean before sea snakes (~7 mya) and kraits (~13 mya) and just after marine homalopsids (~18 mya).

Acrochordus in contemporary aboriginal artwork by Chris Liddy (Moonggun),
showing the embryos inside the snake in the northern Australian style
One of the most interesting things about filesnakes is that Aboriginal Australians collect and eat them in some areas. Mostly this is done at the end of the Australian dry season, in November, when water levels are lowest and the snakes are easiest to find and capture. Although the snakes themselves don't generally put up much resistance, the old women who hunt them do so by wading into murky waters filled with crocodiles and feel under overhanging banks, weed beds, and logs, sometimes collecting over 30 snakes per person-hour. Often the snakes are killed immediately by biting their necks. The pregnant females are highly prized for their embryos, which are cooked on hot ashes, eaten like popcorn, and called 'cookies' by Aboriginal children.



1 Not to be confused with African Filesnakes (genus Mehelya), which are so-named not for their texture but for their cross-sectional shape, which resembles a triangular file.


ACKNOWLEDGMENTS

Thanks to Chris LiddyMatt Summerville, Darryl Houston, M. & P. Fogden, Jordan de Jong, Stephen Zozaya, Jason Isley, and Dick Bartlett for their photos, and to Rick Shine for information on tracking down Darryl Houston.

REFERENCES

Boulenger, G. A. 1893. Catalogue of the snakes in the British Museum (Natural History). Trustees of the British Museum, London <link>

Feder, M. E. 1980. Blood oxygen stores in the file snake, Acrochordus granulatus, and in other marine snakes. Physiological Zoology 53:394-401 <link>

Heatwole, H. and R. Seymour. 1975. Pulmonary and cutaneous oxygen uptake in sea snakes and a file snake. Comparative Biochemistry and Physiology Part A: Physiology 51:399-405 <link>

Houston, D. and R. Shine. 1994. Movements and activity patterns of Arafura filesnakes (Serpentes: Acrochordidae) in tropical Australia. Herpetologica 50:349-357 <link>

Lillywhite, H. B., A. W. Smits, and M. E. Feder. 1988. Body fluid volumes in the aquatic snake, Acrochordus granulatus. Journal of Herpetology 22:434-438 <link>

Madsen, T. and R. Shine. 2000. Rain, fish and snakes: climatically driven population dynamics of Arafura filesnakes in tropical Australia. Oecologia 124:208-215 <link>

Magnusson, W. A. 1979. Production of an embryo by an Acrochordus javanicus isolated for seven years. Copeia 1979:744-745

McDowell, S. B. 1975. A catalogue of the snakes of New Guinea and the Solomons, with special reference to those in the Bernice P. Bishop Museum. Part II. Anilioidea and Pythoninae. Journal of Herpetology 9:1-79 <link>

McDowell, S. B. 1979. A catalogue of the snakes of New Guinea and the Solomons, with special reference to those in the Bernice P. Bishop Museum. Part III. Boinae and Acrochordoidea (Reptilia, Serpentes). Journal of Herpetology 13:1-92 <link>

Povel, D. and J. Van Der Kooij. 1996. Scale sensillae of the file snake (Serpentes: Acrochordidae) and some other aquatic and burrowing snakes. Netherlands Journal of Zoology 47:443-456 <link>

Pyron RA, Burbrink F, Wiens JJ, 2013. A phylogeny and revised classification of Squamata, including 4161 species of lizards and snakes. BMC Biology 13 <link>

Rasmussen, A. R., J. C. Murphy, M. Ompi, J. W. Gibbons, and P. Uetz. 2011. Marine Reptiles. PLoS ONE 6:e27373 <link>

Rieppel, O. and H. Zaher. 2001. The development of the skull in Acrochordus granulatus (Schneider)(Reptilia: Serpentes), with special consideration of the otico‐occipital complex. Journal of Morphology 249:252-266 <link>

Sanders KL, Mumpuni, Hamidy A, Jead J, Gower D, 2010. Phylogeny and divergence times of filesnakes (Acrochordus): inferences from morphology, fossils and three molecular loci. Molecular Phylogenetics and Evolution 56:857-867 <link>

Seymour, R., G. Dobson, and J. Baldwin. 1981. Respiratory and cardiovascular physiology of the aquatic snake, Acrochordus arafurae. Journal of Comparative Physiology 144:215-227 <link>

Shine R, 1995. Australian Snakes: A Natural History Ithaca, New York: Cornell University Press <link>

Shine, R. 1986. Sexual differences in morphology and niche utilization in an aquatic snake, Acrochordus arafurae. Oecologia 69:260-267 <link>

Shine, R. 1986. Ecology of a low-energy specialist: food habits and reproductive biology of the arafura filesnake (Acrochordidae). Copeia 10:424-437 <link>

Shine, R. 1986. Predation upon filesnakes (Acrochordus arafurae) by aboriginal hunters: selectivity with respect to body size, sex and reproductive condition. Copeia 10:238-239 <link>

Shine, R. and D. Houston. 1993. Acrochordidae. in C. Glasby, G. Ross, and P. Beesley, editors. Fauna of Australia. AGPS, Canberra <link>

Shine, R., P. Harlow, J. S. Keogh, and Boeadi. 1995. Biology and commercial utilization of acrochordid snakes, with special reference to karung (Acrochordus javanicus). Journal of Herpetology 29:352-360 <link>

Voris, H. K. and G. S. Glodek. 1980. Habitat, diet, and reproduction of the file snake, Acrochordus granulatus, in the straits of Malacca. Journal of Herpetology 14:108-111 <link>

Creative Commons License

Life is Short, but Snakes are Long by Andrew M. Durso is licensed under a Creative Commons Attribution-NonCommercial-NoDerivs 3.0 Unported License.

Wednesday, July 30, 2014

Tetrodotoxin-resistant snakes


An adult male Taricha granulosa in breeding condition.
There is enough tetrodotoxin in this newt to kill you
and about 29 other people.
Gartersnakes eat newts. I mentioned this remarkable fact in my article on the Scientific American Guest Blog, but it's interesting enough to warrant a more detailed treatment. In 1990, Edmund D. Brodie III and his father, Edmund D. Brodie Jr, published a paper in the journal Evolution that provided the first evidence of a pair of species in a highly coupled arms race. Previously, the concept of an arms race had been criticized because the potential cost to the prey (loss of life) was perceived as more dire than the potential cost to the predator (merely the loss of dinner). This imbalance, known as the life-dinner principle, led scientists to suggest that tightly co-evolving arms races between predators and prey could not exist, because selection pressure on the predator would always be less than that on the prey. However, reasoned Brodie & son, if the prey's defenses are lethal, then selection might be equally strong on both predator and prey, because only highly resistant predators could survive a predation event. This is the case in the predator-prey dynamic between the Rough-skinned Newt (Taricha granulosa) and the Common Gartersnake (Thamnophis sirtalis), which is centered around a toxin called tetrodotoxin.

Chemical structure of tetrodotoxin
Tetrodotoxin is a very interesting chemical. James Bond was poisoned with it at the end of From Russia with Love (and saved by an antidote, which does not exist in real life). It's responsible for the tingling sensation caused by eating properly prepared fugu (and woe betide those who consume this Japanese pufferfish dish improperly prepared). Named after the pufferfish family, it is found in a wide variety of organisms, from flatworms to the blue-ringed octopus, its biological origins are enigmatic. Many species are thought to sequester it from symbiotic bacteria, although some, including newts, are believed to be capable of synthesizing it themselves. In the lab, tetrodotoxin is created under conditions of extreme heat and pressure, and how this molecule is generated inside of living cells is a mystery. Furthermore, it is an extremely potent poison: tetrodotoxin binds to and occludes the extracellular pore of voltage-gated ion channels embedded in muscle cell membranes, preventing the flow of sodium ions into the cell and interrupting the action potentials necessary for muscle contraction. This is not unlike the effect produced by local anesthetics, which also block sodium channels, but with two important differences: they do so from the inside of the cell and their effects are reversible.

Map of gartersnake resistance to tetrodotoxin
Outside of the range of the Rough-skinned Newt,
gartersnakes have essentially no resistance.
Figure from Brodie Jr. et al 2002
The elder Brodie showed in 1968 that many predators died if they were forced to eat newt, including bobcats, herons, kingfishers, moles, weasels, bass, catfish, and most snakes, including racers, rattlesnakes, gophersnakes, whipsnakes, rubber boas, and sharp-tailed snakes. Notably, Common Gartersnakes survived, although they were temporarily incapacitated. Brodie realized that he could measure snake toxin resistance by timing how long a snake was incapacitated for or how much its crawling speed slowed down when it was given a standardized dose of tetrodotoxin. Using this method for measuring resistance, the Brodies demonstrated that newt toxicity and gartersnake toxin resistance co-vary predictably across most of the Pacific Northwest; for example, on Vancouver Island, newts have very low levels of TTX and gartersnakes have almost no resistance to the toxin, whereas in central Oregon and in California's San Francisco Bay area, newts are tens of thousands of times more toxic and gartersnakes have correspondingly high resistance (for the most part, but read on!).

Three species of TTX-resistant snakes:
top: Amphiesma pryori
middle: Erythrolamprus epinephelus
bottom: Rhabdophis tigrinus
It's now known that a number of different snake species are resistant to tetrodotoxin and are capable of eating newts and other TTX-laden prey with impunity. These include two other species of gartersnake, the Santa Cruz gartersnake (Thamnophis atratus), which also eats Rough-skinned Newts, and the aquatic garter snake (Thamnophis couchii), which preys on California Newts (Taricha torosa). A Japanese newt, Cynops ensicauda, is eaten by Pryer's Keelback (Amphiesma pryeri). Some frogs also have tetrodotoxin, and two species, an Atelopus toad in Central American and a Polypedates treefrog in eastern Asia, are respectively eaten by the dipsadine Erythrolamprus [Liophis] epinephelus and the natricine Rhabdophis tigrinus. Not only has tetrodotoxin resistance also arisen in these other species of snakes around the world, but the mechanism, which involves changing the shape of the sodium channel pore so that the toxin binds less tightly, has evolved the exact same way in each lineage of snakes, via functionally identical mutations to the gene sequences. This is remarkable because these snakes are moderately but not very closely related to one another, and even more so because pufferfish also have many of the same mutations. These mutations are not found in humans, rats, most snakes, or other non-resistant vertebrates. All this suggests that there are a limited number of ways that evolution can change a sodium channel to make it more resistant to TTX and still maintain its function. In most cases, these and other natricine and dipsadine snakes are probably resistant to multiple prey toxins, as they are known to regularly consume other toxic amphibians and invertebrates.

Common Gartersnake (Thamnophis sirtalis)
from Oregon's Willamette Valley, where newt toxicity and
snake resistance are both at their peak
Although all newts and some other amphibians possess TTX, T. granulosa is many times more toxic than any other species, and its primary predator is many times more resistant than any other snake. Common Gartersnakes themselves actually retain sufficient quantities of newt-derived TTX in their liver for one to two months after eating newts to severely incapacitate or kill their predators, which was the general subject of my original article. Whether or not any of the other TTX-resistant species sequester the toxin remains unknown, although it seems likely. In a few places, Common Gartersnakes have evolved such high resistance to TTX that they have effectively "won" their arms race with their newts. Because snake TTX resistance apparently evolves in a stepwise fashion, with each new mutation to the snake sodium channel pore structure rapidly making it much tougher for TTX to bind tightly, gartersnakes are capable of making quicker leaps in the arms race than are newts, which presumably must evolve higher toxicity by increasing the amount of TTX they produce. Eventually, some gartersnakes seem to have reached a point where no amount of TTX could incapacitate them, so their newt populations (which were already pretty toxic) stopped being selected to produce more toxin. Since we don't really know how they get their toxin in the first place, they might be limited in their ability to produce or sequester it or its precursors.

There's much left to discover about this system, which is perhaps one of the most interesting in snake biology. Where are newts getting tetrodotoxin from? How many other times has TTX resistance evolved in snakes, and has it happened the same way every time? To what extent are gartersnakes using newt-derived TTX to protect against their own predators? Someday, we will find out.

ACKNOWLEDGMENTS

Thanks to current and former members of the Brodie lab, especially Dr. Edmund D. "Doc" Brodie Jr., for discussing this system with me over the last three years.

REFERENCES

Brodie Jr, E. D. 1968. Investigations on the skin toxin of the adult rough-skinned newt, Taricha granulosa. Copeia 1968:307-313 <link>

Brodie III, E. and E. Brodie Jr. 1999. Costs of exploiting poisonous prey: evolutionary trade-offs in a predator-prey arms race. Evolution 53:626-631 <link>

Brodie III, E., C. Feldman, C. Hanifin, J. Motychak, D. Mulcahy, B. Williams, and E. Brodie Jr. 2005. Parallel arms races between garter snakes and newts involving tetrodotoxin as the phenotypic interface of coevolution. Journal of Chemical Ecology 31:343-356 <link>

Geffeney, S., E. Brodie Jr, P. Ruben, and E. Brodie III. 2002. Mechanisms of adaptation in a predator-prey arms race: TTX-resistant sodium channels. Science 297:1336-1339 <link>

Geffeney, S., E. Fujimoto, E. Brodie, and P. Ruben. 2005. Evolutionary diversification of TTX-resistant sodium channels in a predator–prey interaction. Nature 434:759-763 <link>

Hanifin, C. T. and E. D. Brodie Jr. 2008. Phenotypic mismatches reveal escape from arms-race coevolution. PLoS Biology 6:e60 <link>

Feldman, C. R., E. D. Brodie, and M. E. Pfrender. 2012. Constraint shapes convergence in tetrodotoxin-resistant sodium channels of snakes. Proceedings of the National Academy of Sciences 106:13415-13420 <link>

Stokes, A. N., P. K. Ducey, L. Neuman-Lee, C. T. Hanifin, S. S. French, M. E. Pfrender, E. D. Brodie, III, and E. D. Brodie Jr. 2014. Confirmation and distribution of tetrodotoxin for the first time in terrestrial invertebrates: two terrestrial flatworm species (Bipalium adventitium and Bipalium kewense). PLoS ONE 9:e100718 <link>

Williams, B. L. and R. L. Caldwell. 2009. Intra-organismal distribution of tetrodotoxin in two species of blue-ringed octopuses (Hapalochlaena fasciata and H. lunulata). Toxicon 54:345-353 <link>

Williams, B. L., E. D. Brodie Jr., and E. D. Brodie III. 2004. A resistant predator and its toxic prey: persistence of newt toxin leads to poisonous (not venomous) snakes. Journal of Chemical Ecology 30:1901-1919 <link>

Creative Commons License

Life is Short, but Snakes are Long by Andrew M. Durso is licensed under a Creative Commons Attribution-NonCommercial-NoDerivs 3.0 Unported License.

Thursday, June 26, 2014

Why do snakes flick their tongues?


You've probably seen it before - a snake extends its forked tongue, waves it around rapidly, then retracts it. Creepy, right? What do they do that for anyway? Theories explaining the forked tongues of snakes are many and ancient. Aristotle reasoned that it provided snakes with "a twofold pleasure from savours, their gustatory sensation being as it were doubled". 17th century Italian astronomer Giovanni Hodierna thought snake tongues were for cleaning dirt out of their noses. Several writers in the 1600s claimed to have watched snakes catch flies or other animals between the forks of their tongues, using them like forceps. It is a common myth even today that snakes can sting you with their tongues. Watch this video to convince yourself that none of those hypotheses is likely:


A Southern Pacific Rattlesnake (Crotalus oreganus helleri)
touching its tongue tips to the ground
Actually, Aristotle probably got it the closest, as we'll see. Over the last 20 years, members of the laboratory of Kurt Schwenk, a University of Connecticut ecologist and evolutionary biologist, have published a great deal of interesting research on the function of snake tongues. Most animals with tongues use them for tasting, to clean themselves or others, or to capture or manipulate their prey. A few, including humans, also use them to make sounds. Snakes do not use their tongues for any of these things, although they come closest to tasting. A more accurate description of what a snake uses its tongue for is collecting chemicals from the air or ground so that the snake can smell them. By itself, a snake's tongue can neither smell nor taste. Snake tongues have no taste buds. Instead, the tongue is best thought of as a specially-shaped chemical collector. This is because the actual smelling - the conversion of the chemicals into electrical signals sent to the brain by way of receptors - takes place not on the tongue but in the vomeronasal or Jacobson's Organ, which is in the roof of the mouth (and, incidentally, also the name of a pretty sweet band). For a long time everyone thought that the tongue delivered chemicals directly to the Jacobson's Organ, because both the Jacobson's Organ and the pathways that lead to it are paired just like the tips of the tongue. Even this recent Encyclopedia Britannica figure falls victim to this assumption (edit: a few days after this article posted, Britannica Earth & Life Science editor John P. Rafferty tweeted me to let me know that they had updated the article, including a new diagram). In fact this is, as Schwenk put it, a red herring.

Instead, x-ray movies have revealed that the tongue does not move inside the closed mouth, but that each side of the tongue deposits the chemicals it has collected onto pads on the floor of the mouth (called the anterior processes of the sublingual plicae, in anatomical jargon) as the mouth is closing. It is most likely these plicae that deliver the sampled molecules to the entrance of the Jacobson's Organ (the vomeronasal fenestrae) when the floor of the mouth is elevated to come into contact with the roof following a tongue flick. Further evidence for this heretical notion is that geckos, skinks, and other lizards lack deeply-forked tongues but deliver chemicals to their vomeronasal organs just fine, and in fact so do turtles and many mammals and amphibians (although in none of these groups is the Jacobson's Organ as well-developed as in squamates).

Cross-sectional structure of one half of the Jacobson's Organ,
including the sensory epithelium, lumen, and mushroom body
From Døving & Trotier 1998
Because it is forked, the tongue of a snake can collect chemical information from two different places at once, albeit places that are fairly close together by human standards. Snakes often spread the tips of their tongues apart when they are extended, sometimes to a distance twice as wide as their head. This is significant because it allows them to detect chemical gradients in the environment, which gives them a sense of direction - in other words, snakes use their forked tongues to help them smell in 3-D. Owls use their asymmetrical ears in this way. Snakes and owls use similar neural circuitry to compare the signal strength delivered from each side of the body and determine the direction that a smell or a sound is coming from. (Humans do this with our hearing too, but we're not as good at it). This ability makes it possible for snakes to follow trails left by their prey or by potential mates. In the 1930s, before guidelines on the ethical use of animals in research were as strict, German biologist Herman Kahmann experimentally removed the forked part of snakes' tongues and found that they could still respond to smells, but that they had lost their ability to follow scent trails.1 Later experiments by John Kubie and Mimi Halpern refined and confirmed this result using the more humane method of blocking the entrance to the Jacobson's Organ on one side and found that these snakes turned in a circle toward the unblocked side when they tried to follow a trail (although one recent experiment that severed the vomeronasal nerve on one side did not support this hypothesis).

Male (left) and female (right)
Copperhead tongue
Figure from Smith et al. 2008
In the 1980s, snake biologist Neil Ford watched how male garter snakes used their tongues when they were following pheromone trails left behind by females. He found that if both tips of the male snake's tongue fell within the width of the trail, the snake continued slithering straight ahead. However, when one tip or the other fell outside the edge of the trail, the snake turned his head away from that tip and back towards the pheromone trail, and his body followed. Following this simple rule allowed the snakes to perform trail-following behavior that was both accurate and directed. If both tongue tips ever touched the ground outside of the trail, the male would stop and swing his head back and forth, tongue-flicking, until he relocated the trail. Snake ecologist Chuck Smith found evidence that male Copperheads have longer, more deeply-forked tongues than females, which presumably enhances their ability to find mates. Although sexual dimorphism is rare in snakes, differences in tongue size are likely to be present other species as well. Scent-trailing is probably also quite helpful to snakes tracking down prey, including for sit-and-wait predators like vipers, which have evolved smelly but non-toxic venom components, about which I've written before, to help them relocate bitten and envenomated prey items. Many lizards that are active hunters also have deeply forked tongues which they spread apart when tongue-flicking, whereas lizards such as geckos and iguanids are mostly either ambush predators or herbivores and have blob-like tongues. Whether following mate or prey, how snakes and lizards determine that they are following the scent trail in the right direction is unknown.

Different types of tongue flicks
From Daghfous et al. 2012
When following a scent-trail, snakes simply touch their tongue tips down to the ground to pick up the chemical information lying there (top panel, left). But snakes can also use a different type of tongue-flick (bottom two panels) to sample airborne chemicals. Snakes often wave their tongues in the air without putting them in contact with anything. The tongue creates self-reinforcing air vortices. Vortices formed in the water by boats drift away from the boat as they form. Bill Ryerson, another student in the Schwenk lab, found that the vortices created in the air by snake tongues have a special property - they do not drift away but rather stay in the vicinity of the tongue, where they can be sampled repeatedly as the tongue skirts the part of each vortex where the air velocity is the highest. Oscillating tongue-flicks are unique to snakes. They usually last 2-3 times longer and can sample 100 times as much air as the simple downward extension of the tongue. The tongue then transfers these molecules to the Jacobson's Organ via the same route described above. Evidence suggests that male Copperheads can also find females using oscillating tongue-flicks to detect airborne pheromones, although the details of how they determine direction using such dispersed and transient odors are poorly understood. We have much to learn about this incredibly advanced sensory system and the role it has played in the evolutionary success of snakes.




1 Before you lambaste Kahmann too badly, you should also know that he supported his part-Jewish University of Munich colleague Karl von Frisch, who later went on to share the 1973 Nobel Prize in Physiology or Medicine for his discovery of honeybee communication, against Hitler's regime.


ACKNOWLEDGMENTS

Thanks to Bill Ryerson for giving such an engaging talk at SICB 2014 and for talking with me after, so that I was inspired to research and write this piece, and to JustNature and Zack Podratz for allowing me to use their photographs and videos.

REFERENCES

Berkhoudt, H., P. Wilson, and B. Young. 2001. Taste buds in the palatal mucosa of snakes. African Zoology 36:185-188 <link>

Daghfous, G., M. Smargiassi, P.-A. Libourel, R. Wattiez, and V. Bels. 2012. The function of oscillatory tongue-flicks in snakes: insights from kinematics of tongue-flicking in the Banded Water Snake (Nerodia fasciata). Chemical Senses 37:883-896 <link>

Døving, K. B. and D. Trotier. 1998. Structure and function of the vomeronasal organ. Journal of Experimental Biology 201:2913-2925 <link>

Ford, N. B. 1986. The role of pheromone trails in the sociobiology of snakes. Pages 261-278 in D. Duvall, D. Muller-Schwarze, and R. M. Silverstein, editors. Chemical Signals in Vertebrates, Vol 4. Plenum, New York <link>

Gove, D. 1979. A comparative study of snake and lizard tongue‐flicking, with an evolutionary hypothesis. Zeitschrift für Tierpsychologie 51:58-76 <link>

Halpern, M. and S. Borghjid. 1997. Sublingual plicae (anterior processes) are not necessary for garter snake vomeronasal function. Journal of Comparative Psychology 111:302-306 <link>

Parker, M. R., B. A. Young, and K. V. Kardong. 2008. The forked tongue and edge detection in snakes (Crotalus oreganus): an experimental test. Journal of Comparative Psychology 122:35-40 <link>

Schwenk, K. 1994. Why snakes have forked tongues. Science 263:1573-1577 <link>

Smith, C. F. 2007. Sexual dimorphism, and the spatial and reproductive ecology of the copperhead snake, Agkistrodon contortrix. PhD Dissertation. University of Connecticut <link>

Smith, C., K. Schwenk, R. Earley, and G. Schuett. 2008. Sexual size dimorphism of the tongue in a North American pitviper. Journal of Zoology 274:367-374 <link>

Ryerson, W. G. and K. Schwenk. 2012. A simple, inexpensive system for digital particle image velocimetry (DPIV) in biomechanics. Journal of Experimental Zoology Part A: Ecological Genetics and Physiology 317:127-140 <link>

Young, B. A. 1990. Is there a direct link between the ophidian tongue and Jacobson's organ? Amphibia-Reptilia 11:263-276 <link>

Creative Commons License

Life is Short, but Snakes are Long by Andrew M. Durso is licensed under a Creative Commons Attribution-NonCommercial-NoDerivs 3.0 Unported License.

Tuesday, May 27, 2014

Snakes long-lost

Click here to read this post in Spanish!
Haga clic aquí para leer este blog en español!

Alternate title suggested by Mike Pingleton: Not all who slither are lost

Clarión Nightsnake (Hypsiglena unaocularis)
Photograph from Mulcahy et al. 2014
Just over one year ago, a team of scientists from the Smithsonian and the Red de Interacciones Multitróficas rediscovered a species of nightsnake (genus Hypsiglena) on remote Clarión Island in the eastern Pacific Ocean, over 400 miles southwest of Cabo San Lucas. Called the Clarión Nightsnake (Hypsiglena unaocularus), it was originally discovered by the renowned American naturalist William Beebe in 1936, during a nocturnal sea turtle nesting survey. Because Clarión Island is only accessible via military escort, biologists have not visited the island frequently since Beebe's time, and in 1955 herpetologist Bayard Brattstrom suggested that perhaps Beebe's locality information had been an error, since only a single specimen existed and several other Clarión Island expeditions had not turned up another. However, the type specimen collected by Beebe, resting in the herpetology collection of New York's American Museum of Natural History, was sufficiently distinct from any other Hypsiglena specimen that it prompted herp phylogeographer Dan Mulcahy to reexamine Beebe's book and field notes, which contained a pretty clear description of the circumstances under which Beebe found the snake:

“We walked on, flashing the light all around. Not far from the water on the black lava
I saw a small dark brown snake. It seemed to be unlike the one I had found in daylight,
having lines of black spots on the body, so I picked it up and cached it in my shirt.”
(p. 282 of Zaca Venture)

Location of Clarión Is.
From Mulcahy et al. 2014
Click to enlarge
As their name implies, Nightsnakes mostly come out at night (although I found one in southern Utah at about 9:30 in the morning a few weeks ago), and even then they are normally only active under certain conditions - in particular, they prefer to be active when there is not much moonlight, such as on cloudy nights or when the moon is new. Even if one is specifically searching for Nightsnakes, they can be difficult to find. Combined with their generally secretive nature, this could explain the failure of several Clarión Island expeditions to find the Clarión Nightsnake - until Mulcahy's expedition in May of 2013, which found 11 individuals in 15 days. Using phylogenetics, they determined that the Clarión Nightsnake is most closely related to the Santa Catalina Nightsnake (H. catalinae), which is found on Santa Catalina Island in the Gulf of California (which is not the same as the well-known Santa Catalina Island off of the US state of California). Nightsnakes are found all around the shoreline of the Gulf of California, and they are obviously exceptional over-water dispersers, because they occur on many of the islands in that region as well.

This remarkable story of rediscovery is a testament to the kind of attention to detail that it takes to be a good natural historian, but it's not the only species of snake that has been rediscovered many years after its initial description. Here are a few others:

Angel’s Stream Snake (Paratapinophis praemaxillaris)
Photograph from Murphy et al. 2008
Angel’s Stream Snake (Paratapinophis praemaxillaris) was described from two newborn specimens from northern Laos in 1929. At that time it was placed into a new genus because of an unusual process on its nose, but a few years later it was moved into the cosmopolitan genus Opisthotropis. Two more specimens were collected in the 1980s, but it wasn't until 2008, when five adult specimens were collected from a pool at the base of a waterfall on the Nan River in northern Thailand, that it became clear that the nose structure was actually an egg tooth, a structure normally lost a few days after hatching. At that time, Paratapinophis was placed back into its own genus because of several other formerly-overlooked unique features, including sexually dimorphic color, pattern, and scale ornamentation. Like most other natricines, this species eats fishes.

Chersodromus rubriventris
Photograph from Ramírez-Bautista et al. 2013
Chersodromus rubriventris, the Redbelly Earth Runner, was discovered in a cloud forest in San Luis Potosí, Mexico, just after the end of World War II and described a few years later by American herpetologist and spy Edward H. Taylor, who also used his biology as a cover for work in the Philippines, Russia, and Sri Lanka during both world wars. Two other specimens, one from the late 1960s and the other from the early 1980s, were known, but in 2013, a team of herpetologists from the Universidad Autónoma del Estado de Hidalgo found three individuals in a cloud forest in nearby Hidalgo, doubling the number of specimens and photographing the snake alive for the first time. Stomach contents included beetle larvae and ants, both of which are unusual prey for a dipsadid snake.

Atractus wagleri
Photograph from Passos & Arredondo 2009
The genus Atractus, a group of burrowing snakes found from Panama to Argentina, is the most diverse alethinophidian snake genus, with over 130 species, most of which are only known from a few specimens. Recently Paulo Passos of the Brazilian National Museum matched up several previously mis- or unidentified Atractus specimens in South American museums with their species, constituting rediscoveries of sorts. For example, Wagler's Ground Snake (Atractus wagleri) was described in 1945 from a single specimen from western Colombia, and that specimen was lost in a fire in 1948. In 2009 Passos located three additional specimens of this poorly known snake in museums in Colombia. Another species, the Modest Ground Snake (Atractus modestus), was described in 1894 by the great Belgian zoologist George Boulenger, from a single specimen from western Ecuador. In 2007 Passos located more specimens in Ecuadorian museums, expanding the range of the species across most of the country. Although species of Atractus are seemingly quite rare, occurring at high elevations and having secretive fossorial habitats, a large number of Atractus specimens remain misidentified or unidentified in herpetological collections, so our knowledge of these snakes stands to improve dramatically as these are examined and described.

Argus Snail Sucker (Sibon argus)
The Lichen-coloured or Argus Snail Sucker (Sibon argus) is an extremely slender arboreal dipsadine snake with eye-like ("ocellate") spots. It was originally described from a single specimen from southeastern Costa Rica in 1876, by renowned paleontologist Edward Drinker Cope (who feuded with O.C. Marsh in the "Bone Wars" over who could discover more dinosaurs, the subject of an upcoming film starring Steve Carrell as Cope). The validity of the species was uncertain because of the subsequent description of other gracile snakes with ocellated patterns from the same region. In his classic revision of Neotropical snail- and slug-eating snakes, James Peters suggested that Cope's specimen might be aberrant, or perhaps that it represented one half of a species with strong sexual dimorphism (which is rare in snakes), because the only known S. argus specimen  was a male, and another species, Sibon longifrenis, was known at the time from just two specimens, both females. Males and females of the same species had been described as separate species before. Ultimately, Peters decided that the two species were probably different, and he was proven right in 1992, when tropical herpetologist Jay Savage was preparing his opus on Costa Rican herpetofauna. Savage discovered both male and female specimens that best matched Cope's 1876 S. argus in the collections of the University of Kansas and the Universidad de Costa Rica. The snakes had been collected in evergreen forests in Panama and Costa Rica, near the type locality of S. argus. With Roy McDiarmid, Savage redescribed the species, which has become much more well-known since. A recent study by Julie Ray and colleagues documented a more diverse diet for this species than previously expected, including other gooey prey such as oligochaete worms and frog eggs. Unfortunately for Sibon argus, both of these prey types are in decline in the neotropics, the worms due to overcollection of their bromeliad homes for horticulture, and the amphibians due to the devastating effects of the amphibian chytrid fungus Batrachochytrium dendrobatidis.

Brygophis coulangesi
Photograph from Andreone & Raxworthy 1998
Other examples of rediscovered snakes abound. The Uluguru Worm Snake (Letheobia uluguruensis) was described from four specimens collected in 1926 from the Uluguru Mountains of eastern Tanzania, a mountain range with dozens of endemic species, and was not seen again until 2004, when four were dug up by local people employed by a group of herpetologists from the London Natural History Museum and the University of Glasgow to search for caecilians. Another blindsnake, Typhlops tasymicris, was rediscovered on Union Island, St. Vincent and the Grenadines, in 2010. An entire genus of blindsnake, Xenotyphlops, was rediscovered in Madagascar, in 2007, 102 years after it's description. A rare sea snake, Hydrophis parviceps, was originally collected by the Danish research vessel Dana and described in 1935 and was seen again only once in 1960 until three turned up in fisheries bycatch off of Vietnam in 2001. Another species of rare sea snake, H. bituberculatus, was rediscovered off Sri Lanka in the late 1980s, over 100 years after the first one was collected (although the fishermen who collected the specimen were so secretive that they refused to divulge the location). One of the rarest snakes in Madagascar, a slow-moving reddish-orange species called Brygophis coulangesi, was first collected in 1968, when one fell from a tree and vomited up a chameleon, with a second specimen found on a cloudy, rainy night during a rain forest survey in 1998, over 300 miles to the north of the first. A second specimen of another Malagasy lamprophiidAlluaudina mocquardi, was discovered in a pitch-black cave in northern Madagascar in 1982, 50 years after the first was found in a different cave nearby. I don't think any more have been found since, so this one should be getting ready to be rediscovered again soon (edit: City University of New York snake biologist Frank Burbrink informed me that on his recent trip to Madagascar they turned up an Alluaudina mocquardi in tsingy rock at Ankarana - see photo here)!

March 2010 Herp. Review cover
featuring Crotalus lannomi
A high-profile rediscovery graced the cover of the March 2010 issue of the journal Herpetological Review, which featured a photograph of a long-sought-after species of rattlesnake, the Autlán Long-tailed Rattlesnake (Crotalus lannomi). Discovered in the summer of 1966 by Joseph Lannom, C. lannomi became sort of a “holy grail” of rattlesnakes in the decades that followed, as numerous herpetologists ventured into the mountains of western Jalisco in search of it. They were stymied by heavy fog and dangerous flooding, roads with treacherous curves and highway robberies, and drug-related violence. In 2008, five specimens of C. lannomi were found in the foothills of Colima, roughly 50 km from the type locality in Jalisco, in some of Mexico's most pristine forest habitat.

Although most of this was new to me, I've actually written about a different rediscovered viper before, the Spider-tailed Adder (Pseoducerastes urarachnoides) of Iran, which was discovered in 1968 and was at first thought to have either a tumor, a congenital defect, or a growth caused by a parasite, or maybe a spider clinging to its tail (turns out its tail is modified into a lure to attract spider-eating birds). Also, in one of my first articles, I wrote about the South Florida Rainbow Snake (Farancia erytrogramma seminola), described by Wilfred T. Neill in 1964 from Fisheating Creek in Glades County near Lake Okeechobee, Florida, and presumed extinct, never seen again since. To the best of my knowledge this subspecies has yet to be rediscovered, despite a $500 reward from the Center for Snake Conservation and Center for Biological Diversity. (Edit: a diligent reader reminded me that I also wrote about another snake that hasn't been seen since 1975 in one of my earliest articles, the Round Island Burrowing Boa, Bolyeria multocarinata).

Undoubtedly there are numerous snake species left to be discovered and rediscovered, and in many cases almost nobody's out there looking. The Reptile Database has predicted that the total number of described reptile species will surpass 10,000 in 2014, and that non-avian reptiles will perhaps eclipse birds in diversity soon after that. With snakes currently at 3,466, representing just over one third of reptiles, maybe you will be the next to rediscover a snake thought lost!

ACKNOWLEDGMENTS

Thanks to Dan Mulcahy and Don Filipiak for the use of their photographs.

REFERENCES

Andreone, F. and C. Raxworthy. 1998. The colubrid snake Brygophis coulangesi (Domergue 1988) rediscovered in north-eastern Madagascar. Tropical Zoology 11:249-257 <link>

Beebe, CW. 1938. Zaca Venture. Harcourt, Brace and Co. Inc., New York <link>


Cope, E. D. 1875. On the batrachia and reptilia of Costa Rica : With notes on the herpetology and ichthyology of Nicaragua and Peru. Journal of the Academy of Natural Sciences Philadelphia 2:93-157 <link>


Gower, D. J., S. P. Loader, and M. Wilkinson. 2004. Assessing the conservation status of soil‐dwelling vertebrates: Insights from the rediscovery of Typhlops uluguruensis (Reptilia: Serpentes: Typhlopidae). Systematics and Biodiversity 2:79-82 <link>


Lanza, B. 1990. Rediscovery of the Malagasy colubrid snake Alluaudina mocquardi Angel 1939. Tropical Zoology 3:219-223 <link>


Mulcahy, D. G., J. E. Martínez-Gómez, G. Aguirre-León, J. A. Cervantes-Pasqualli, and G. R. Zug. 2014. Rediscovery of an endemic vertebrate from the remote Islas Revillagigedo in the eastern Pacific Ocean: The Clarión Nightsnake lost and found. PLoS ONE 9:e97682 <link>


Mulcahy, D. G. and J. R. Macey. 2009. Vicariance and dispersal form a ring distribution in nightsnakes around the Gulf of California. Molecular Phylogenetics and Evolution 53:537-546 <link>


Murphy, J. C., T. Chan-Ard, S. Mekchai, M. Cota, and H. K. Voris. 2008. The rediscovery of Angel’s Stream Snake, Paratapinophis praemaxillaris Angel, 1929 (Reptilia: Serpentes: Natricidae). The Natural History Journal of Chulalongkorn University 8:169-183 <link>


Passos, P. and J. C. Arredondo. 2009. Rediscovery and redescription of the Andean earth-snake Atractus wagleri (Reptilia: Serpentes: Colubridae). Zootaxa 1969:59-68 <link>


Passos, P., D. F. Cisneros-Heredia, and D. Salazar-V. 2007. Rediscovery and redescription of the rare Andean snake Atractus modestus. The Herpetological Journal 17:1-6 <link>


Peters, J. A. 1960. The snakes of the subfamily Dipsadinae. Miscellaneous Publications of the Museum of Zoology, University of Michigan 114:1-228 <link>


Ramírez-Bautista, A., C. Berriozabal-Islas, R. Cruz-Elizalde, U. Hernández-Salinas, and L. Badillo-Saldaña. 2013. Rediscovery of the snake Chersodromus rubriventris (Squamata: Colubridae) in cloud forest of the Sierra Madre Oriental, México. Western North American Naturalist 73:392-398 <link>


Rasmussen, A. R. 1992. Rediscovery and redescription of Hydrophis bituberculatus Peters, 1872 (Serpentes: Hydrophidae). Herpetologica 48:85-97 <link>


Rasmussen, A. R., J. Elmberg, K. L. Sanders, and P. Gravlund. 2012. Rediscovery of the rare sea snake Hydrophis parviceps Smith 1935: identification and conservation status. Copeia 2012:276-282 <link>


Ray, J. M., C. E. Montgomery, H. K. Mahon, A. H. Savitzky, and K. R. Lips. 2012. Goo-eaters: Diets of the Neotropical snakes Dipsas and Sibon in central Panama. Copeia 2:197-202 <link>


Reyes-Velasco, J., C. I. Grünwald, J. M. Jones, and G. N. Weatherman. 2010. Rediscovery of the rare Autlán Long-tailed Rattlesnake, Crotalus lannomi. Herpetological Review 41:19-25 <link>


Rodríguez, M. J. R., E. J. Bentz, D. P. Scantlebury, R. R. John, D. P. Quinn, J. S. Parmerlee Jr, R. W. Henderson, and R. Powell. 2011. Rediscovery of the Grenada Bank endemic Typhlops tasymicris (Squamata: Typhlopidae). Journal of Herpetology 45:167-168 <link>


Savage, J. M. and R. W. McDiarmid. 1992. Rediscovery of the Central American colubrid snake, Sibon argus, with comments on related species from the region. Copeia 1992:421-432 <link>


Taylor, E. H. 1949. A preliminary account of the herpetology of the state of San Luis Potosí, Mexico. University of Kansas Science Bulletin 33:169-215 <link>


Wallach, V., V. Mercurio, and F. Andreone. 2007. Rediscovery of the enigmatic blind snake genus Xenotyphlops in northern Madagascar, with description of a new species (Serpentes: Typhlopidae). Zootaxa 1402:59-68 <link>


Weaver, R. E. 2010. Activity Patterns of the Desert Nightsnake (Hypsiglena chlorophaea). The Southwestern Naturalist 55:172-178 <link>


Creative Commons License

Life is Short, but Snakes are Long by Andrew M. Durso is licensed under a Creative Commons Attribution-NonCommercial-NoDerivs 3.0 Unported License.
